27971-01A
10
Installation - Assembly Procedures
Reattach the bench assembly to the
pedestals. Be careful of the wires.
Use the
same screws removed earlier. If needed,
the hardware kit also contains these 16
screws. The four #10-32 x 1/2” screws
hold the back of the bench to the
pedestals.
Reconnect the blower harness and click
the shoulder tanner harness into the
pedestal panel.
Unscrew the two brackets from the ballast
drawer and discard. Roll the ballast draw-
er under the bench with the cables toward
the back.
BALLAST DRAWER
#10-32 x 1/2”
To Next Page
