ETS solarforce 648 - Assembly Procedures

27971-01A
5
Installation - Assembly Procedures
Assembly Procedures
The bench requires some disassembly
before installation. Save all screws as
some will be used to reassemble the unit.
Remove the Rear Access
Panel. It is held in place
with four screws.
Remove these three
access plates.
