Installation - Hardware Inventory
Hardware Inventory
Open the hardware bag and remove the
contents. In addition to a pillow, make
sure you have the following hardware
items.
x 1 5/16” Hex wrench
x 2 6mm Hex wrench
(acrylic key)
x 12 Screw, #10 x 1/2”
x 6 Bolt, 3/8-16 x 1 1/4”
hex socket
x 6 Nut, 3/8-16 “nylock”
x 8 Screw, #10-32 x 1/2”
x 4 Washer, #10
x 16 Screw, 1/4-20 x 3/4”
with tooth washer
Tools Needed
#2 Phillips screwdriver
Wrenches (or ratchet wrenches)
in 9/16” and 7/8” sizes
Flat screwdriver
