Installation - Assembly Procedures
Parts needed:
Head-end bench endcap (with shoulder tanners)
Foot-end bench endcap
16 - 1/4-20 x 3/4” screws with tooth washers
Plug the cord from the
shoulder tanners into the
socket on the pedestal as
it is installed.
Secure each endcap to the bench
with 8 screws. The screws attach
from inside the pedestals and bench
assembly, through the holes shown.
NOTE: Canopy removed for illustration purposes only
To Next Page
