22
27330-01A
Care and Maintenance - Lamp and Acrylic Replacement
Lamp and Acrylic Replacement
Introduction
To be assured of maximum tanning effec-
tiveness, change 100W lamps after
approximately 800-1000 hours of use.
Change 160W lamps after 600-800 hours
of use. Tanning will continue after this
time but at a slower rate. To ensure trou-
ble-free operation of your sunbed, replace
the lamp starters whenever the lamps are
replaced.
Maintenance Height Feature
The STARPOWER® 548 offers a conve-
nience feature when maintenance must
be performed. Behind the front access
panel is a release handle (see Final
Adjustments). With the canopy open, pull
this handle and raise the canopy to its
maintenance position, allowing easier
access to lamps, etc. When finished, sim-
ply close the canopy to return to normal
operation.
Opening/Replacing Acrylic Shields
Refer to the illustration on the next page
while reading this instruction. The acrylic
shield in the bench is secured in place by
two quarter-turn latches along the front
aluminum frame of the acrylic. The alu-
minum frame around the acrylic offers
support as well as allowing the acrylic to
hinge open without removing it from the
bed. Use a coin or flat-bladed screwdriv-
er to turn the latches a quarter turn to
open the acrylic. Standing in front of the
bed, lift the long edge of the acrylic. On
the inside of the bench, along the front,
are two supports for the bench acrylic.
Release them from their clips and swing
up to hold the acrylic open. You may
remove the acrylic by lifting it out of its
hinge channel along the back edge.
The other acrylics are held in place by
four quarter-turn latches each. The canopy
and rear lamp module acrylics also swing
open on a hinge and may be removed by
lifting out of the channel along the back
edge.
When you are finished, simply reverse the
above directions to secure the acrylic
shields.
WARNING
Shock hazard.
Disconnect power before removing
any protective covers.
To Next Page
