17
2084606-19-09/17 (translation of the original operating instructions)
Operating Instructions
Non-Contact Safety System CES-A-AEA-02B/CES-A-AEA-04B
The safety outputs are switched off, enabling testing of the complete safety circuit. The diagnostic output DIA of the evalu-
ation unit is also set to HIGH as a monitoring function.
When test input TST is reset, the evaluation unit resets the diagnostic output DIA to LOW, the red LED switches off and
normal operation is continued.
In Manual start operating mode, the start button must be pressed again to start the system.
Important!
After the self-test, the test input TST must be connected to 0 V again or must be disconnected.
