EUCHNER CES-A-AEA-02B User Manual

35
2084606-19-09/17 (translation of the original operating instructions)
Operating Instructions
Non-Contact Safety System CES-A-AEA-02B/CES-A-AEA-04B
EN
11.10. Actuator CES-A-BDA
Ì Round design ∅ 20mm
Ì In combination with read head CES-A-LNA…/CES-A-LCA…
Dimension drawing
∅ 20
2,2
Active face Active face
Technical data
Parameter
Value
Unit
min. typ. max.
Housing material PC plastic
Dimensions ∅ 20x2.2 mm
Weight
0.0008 kg
Ambient temperature -25 - +70 °C
Degree of protection IP67
Installation position Active face opposite read head
Power supply Inductive via read head
