EUCHNER CES-A-AEA-02B User Manual

25
2084606-19-09/17 (translation of the original operating instructions)
Operating Instructions
Non-Contact Safety System CES-A-AEA-02B/CES-A-AEA-04B
EN
11.4. Read head CES-A-LNA-SC
Ì Cube-shaped design 42x25mm
Ì M8 plug connector (snap-action and screw terminals)
Dimension drawing
5,5
∅10
6,8
∅8
∅
4,5
4,6
12
25
min.38
32
±0,1
4232,6
A0
CES-A-L 077715
3
4
1
A0
CES-A-L 077715
20 1,
26,5
Two M4x14 safety screws
included
Cable outlet with angled
connector
Active face
Active face
Typical operating distance
With evaluation unit CES-A-AEA-… and actuator CES-A-BBA
NOTICE
For a side approach direction for the actuator and read head, a minimum distance of s=3mm must
be maintained so that the operating distance of the side lobes is not entered.
Approvals
X
20
15
10
5
20
15
10
5
5
10
15
20
Y
Z
