Operating Instructions
Non-Contact Safety System CES-A-AEA-02B/CES-A-AEA-04B
34
(translation of the original operating instructions) 2084606-19-09/17
11.9. Actuator CES-A-BQA
Ì Cube-shaped design 50x50mm
Dimension drawing for CES-A-BQA
40
±0,15
50
0,25
0
40
±0,15
50
0,25 0
6
20,2
Ø 4,5
-
-
Active face
Technical data
Parameter
Value
Unit
min. typ. max.
Housing material Fortron, reinforced thermoplastic, fully encapsulated
Dimensions 50x50x20.2 mm
Weight 0.07 kg
Ambient temperature -25
- +70
°C
Degree of protection IP67
Installation position Active face opposite read head
Power supply Inductive via read head
