11. Technical data
11.1. Evaluation unit CES-A-AEA-02B
Ì Housing for rail mounting, IP20
Ì Relay output
Ì Two read heads can be connected
Dimension drawing
45
9
9
1
1
4
Suitable for 35mm mounting rail according to EN60715
Switching characteristics
Ì Two safety outputs
(relay outputs)
Ì Two door monitoring outputs
(semiconductor outputs, not
safety outputs)
Approvals
13
14
23
24
24 VO1
13
14
23
24
24
VO
1
24 VO2 24
VO
2
Safety guard
closed
(all actuators detected)
open
(e.g. actuator 1 not in the operating
distance)
Read head 1 Actuator 1 Read head 1

EUCHNER CES-A-AEA-02B Specifications

General

Brand	EUCHNER
Model	CES-A-AEA-02B
Category	Security Sensors
Language	English
