EUCHNER CES-A-AEA-02B User Manual

29
2084606-19-09/17 (translation of the original operating instructions)
Operating Instructions
Non-Contact Safety System CES-A-AEA-02B/CES-A-AEA-04B
EN
11.6. Read head CES-A-LQA-SC
Ì Cube-shaped design 50x50mm
Ì M8 plug connector (snap-action and screw terminals)
Dimension drawing
40
±0,15
50
0,25
0
M8
40
±0,15
50
0,25 0
20
7
6
20,2
Ø 4,5
-
x1
-
Active face
Typical operating distance
10
-30
20
30
Z
Y
10
20
30
-30
30
20
10
X
With actuator CES-A-BBA or CES-A-BCA
10
20
30
Y
10
20
30
20
10
X
30
Z
With actuator CES-A-BQA
Terminal assignment
Read head with connection cable
H11 H12 SH1
BN
WH
1
4
3
Shield
Read head
Evaluation unit
CES-A-AEA-…
Approvals
