EUCHNER CES-A-AEA-02B User Manual

31
2084606-19-09/17 (translation of the original operating instructions)
Operating Instructions
Non-Contact Safety System CES-A-AEA-02B/CES-A-AEA-04B
EN
11.7. Read head CES-A-LMN-SC
Ì Cylindrical design M12
Ì M8 plug connector (snap-action and screw terminals)
Dimension drawing
17
5
32
19,7
R eading distance s
Centre offset m
connected
35
4
8
30
M12x1
M8x1
37
1)
1)
Active face
1) Clear zone (area of the active face without metal housing)
NOTICE
The read head is allowed to be installed as a maximum up to the clear zone (area of the active face
without metal housing).
Typical operating distance
With evaluation unit CES-A-AEA-… and actuator CES-A-BMB
NOTICE
A minimum distance of s=1.2mm must be maintained.
Terminal assignment
Read head with plug connector
H11H12 SH1
1
3
4
BN
WH
Shield
View on the plug
connector of the
read head
Evaluation unit
CES-A-AEA-…
Approvals
2
4
6
6
8
8
X
8
6
4
2
2
4
6
8
8
6
Y
Z
