EUCHNER CES-A-AEA-02B User Manual

Operating Instructions
Non-Contact Safety System CES-A-AEA-02B/CES-A-AEA-04B
32
(translation of the original operating instructions) 2084606-19-09/17
Technical data
Parameter Value Unit
min. typ. max.
Housing material Nickel-plated CuZn housing sleeve
Plastic PBT GF20 cap
Dimensions M12x1, length 38 mm
Weight (incl. 10 m cable) 0.2 kg
Ambient temperature -25 - +85 °C
Ambient pressure
(only of active face in installed condition)
- - 10 bar
Degree of protection IP 67/IP 69/IP 69K
Installation position Any
Method of operation Inductive
Power supply Via evaluation unit
In combination with actuator CES-A-BMB on evaluation unit CES-A-AEA-…
Assured switch-off distance S
ar
- - 10
mm
Operating distance for center offset m=0
1)
- Switch-on distance - 5 -
- Assured switch-on distance S
ao
3.5 - -
- Switching hysteresis 0.1 0.3 -
Connection M8 plug connector (snap-action and screw terminals), 3-pin
Connection cable - - 15 m
1) These values apply to surface installation of the read head in steel.
2) A distance of s=4mm must be maintained for a side approach direction.
3) A distance of s=3mm must be maintained for a side approach direction.
