Operating Instructions
Non-Contact Safety System CES-A-AEA-02B/CES-A-AEA-04B
36
(translation of the original operating instructions) 2084606-19-09/17
11.11. Actuator CES-A-BMB
Ì Cylindrical design M12x75
Ì In combination with read head CES-A-LMN-SC
(operating distance on request for read head CES-A-LNA…/LCA…)
Dimension drawing
11
0,80
6
M12x0,75
Active face
NOTICE
Ì The actuator can be screwed into the M12x0.75 thread provided with the aid of an insertion tool
(order no. 037 662).
Ì Flush installation of the actuator in steel is permissible.
Technical data
Parameter
Value
Unit
min. typ. max.
Housing material Stainless steel
Dimensions M12x0.75, depth 6 mm
Weight
0.002 kg
Ambient temperature -25 - +85 °C
Degree of protection IP 67/IP 69/IP 69K
Installation position Active face opposite read head
Power supply Inductive via read head
