Operating Instructions
Non-Contact Safety System CES-A-AEA-02B/CES-A-AEA-04B
20
(translation of the original operating instructions) 2084606-19-09/17
Technical data of CES-A-AEA-02B
Parameter
Value
Unit
min. typ. max.
Housing material PA6.6 plastic
Dimensions 114x99x45 mm
Weight 0.25 kg
Ambient temperature at U
B
=DC 24 V -20 - +55 °C
Atmospheric humidity, not condensing - - 80 %
Degree of protection IP20
Degree of contamination 2
Mounting Mounting rail 35mm according to DIN EN 60715
Number of read heads Max. two read heads per evaluation unit
Connection (plug-in screw terminals/coded) 0.25 - 2.5 mm²
Operating voltage U
B
(regulated, residual ripple < 5%) 21 24 27 V DC
For the approval according to the following applies
Operation only with UL class 2 power supply or equivalent measures
Current consumption I
B
(with relay energized)
1)
- 220 270 mA
External fuse (operating voltage U
B
) 0.4 - 8 A
Safety contacts 2 (relays with internally monitored contacts)
Switching current (relay outputs)
mA
- at switching voltage AC/DC 1…60 V
1
2)
- 300
- at switching voltage AC/DC 17…30 V 15 - 6,000
- at switching voltage AC 17…230 V 15 - 1,500
Switching load according to
Max. AC 30 V, class 2/max. DC 60 V, class 2
External fuse (safety circuit) according to EN60269-1 6 AgG or 6 A circuit breaker (characteristic B or C)
Utilization category according to EN60947-5-1 AC-12 60 V 0.3 A/DC-12 60 V 0.3 A
AC-12 30 V 6 A/DC-12 30 V 6 A
AC-15 230 V 2 A / DC-13 24 V 3 A
Rated insulation voltage U
i
250 V
Rated impulse withstand voltage U
imp
4 kV
Rated conditional short-circuit current 100 A
Resilience to vibration Acc. to EN60947-5-2
Mechanical operating cycles (relays) 10x10
6
Switching delay from state change
3)
- Two activated actuators - - 290
ms
- One activated actuator - - 210
Discrepancy time of the operating points of both relays
(with two activated actuators)
- - 240 ms
Manual start operating mode
- Start button actuating duration 250 - -
ms
- Start button response delay - 200 300
Current via feedback loop Y1/Y2 5 8 10 mA
Permissible resistance via feedback loop - - 600
W
Ready delay
4)
- 10 12 s
Dwell time
5)
3 - - s
Switching frequency, max
6)
- - 0.25 Hz
Repeat accuracy R acc. to ENIEC60947-5-3 ≤ 10 %
Monitoring outputs (diagnostics DIA, monitoring outputs
01…02, semiconductor output, p-switching, short circuit-pro-
tected)
- Output voltage 0.8xU
B
- U
B
V DC
- Max. load - - 20 mA
Start button input S, test input TST
- Input voltage LOW 0 - 2
V DC
HIGH 15 - U
B
- Input current HIGH 5 8 10 mA
EMC protection requirements Acc. to EN60947-5-3
Reliability values acc. to ENISO13849-1
as a function of the switching current at 24 V DC ≤ 0.1 A ≤ 1 A ≤ 3 A
Category 4
Performance Level (PL) e
PFH
D
1.3x10
-8
1.5x10
-8
Mission time 20 years
Number of switching cycles/year 506 000 100 000 23 000
Diagnostic coverage DC 99 %
MTTF
D
136 years
1) Without taking into account the load currents on the monitoring outputs.
2) If a switching current > 300 mA in conjunction with a switching voltage > 15 V or an inductive or capacitive load is switched once using the relay outputs, it is no longer possible to reliably switch small currents
(< 15 mA) due to the contact erosion on the gold contacts.
3) Corresponds to the risk time according to EN60947-5-3. This is the maximum switch-off delay for the safety outputs following removal of the actuator. In case of EMC interference in excess of the requirements
in accordance with EN60947-5-3, the switch-off delay can increase to max. 430 ms. After a brief actuation < 0.4 s, the switch-on delay can increase to max. 3 s if this is followed immediately by further actuation.
4) After the operating voltage is switched on, the relay outputs are switched off and the monitoring outputs are set to LOW potential during the ready delay. For the visual indication of the delay, the green STATE
LED ashes at a frequency of approx. 15Hz.
5) The dwell time is the time that the actuator must be inside or outside the operating distance.
6) In case of monitoring with feedback loop, the actuators must remain outside the operating distance, e.g. with a door open, until the feedback loop is closed.
