EUCHNER CET-AR Series User Manual

Operating Instructions
Transponder-Coded Safety Switch CET.-AR-…
44
(Translation of the original operating instructions) 2110788-13-03/20
13.2. Dimension drawing for safety switch CET.-AR-…
Version with plug connectors 2 x M12
42
67,2
30
16
130
167
28
25
25
11
5
34
15
74,5
±4 mm
<15>
43,6
52
91,2
CET.-AR...CRA...
CET.-AR...CDA...
20
11,3
SW
19
L
7
8
26,5
10,5
4
(15)
M12
41
15
X1X2
Plunger
Auxiliary
release
LED 2
LED 1
∅ 6.5
For M6 screw
DIN1207/ISO4762
Basic position for
escape release
Release by pressing
With escape release
STATE DIA
With angle connectors
Cable outlet left Cable outlet right
L = 75 or 115mm (depending on version)
The escape release can be extended using the corresponding
accessories.
Version with plug connectors 1 x M12
22
21
With angle connectors
Cable outlet left Cable outlet right
