The escape release is used to open a locked guard from the inside without tools.
DIP
OFF
ON
When release monitoring is active, the system enters into a latching fault when the escape release is actuated.
See System status table, signal sequence incorrect status (DIA red, Lock ashes 1 time).
The system might not enter into a latching fault if the escape release is actuated very slowly.
Important!
Ì It must be possible to actuate the escape release manually from inside the protected area without tools.
Ì It must not be possible to reach the escape release from the outside.
Ì The actuator must not be under tensile stress during manual release.
Ì The escape release meets the requirements of Category B according to ENISO13849-1:2008.
Ì Fit escape release such that operation, inspection and service are possible.
Ì The actuation axis for the escape release must be inserted min. 10 mm into the handle module. Note the information on
the different prole widths in the next chapter.
Ì Adjust escape release axis at right angles to the handle module. See Fig. 4 and Fig. 8.
8.4.1. Preparing escape release
(also see Fig. 7: Preparing escape release on page 17)
Prole width Length required for actuation
axis
Which EUCHNERparts are required? Necessary work steps
Without plates With mounting
plates
(4 mm each)
D D+13 D+21
30 mm 43 mm 51 mm Standard escape release
with 110 mm axis
(order no. 100465)
Shorten to required length
40 mm 53 mm 61 mm Standard escape release
with 110 mm axis
(order no. 100465)
If necessary,
extended actuation axis (order no. 106761)
Without mounting plates:
None
With mounting plates:
Use long actuation axis and protective sleeve and short-
en to required length
45 mm 58 mm 66 mm Standard escape release
with 110 mm axis
(order no. 100465)
and
extended actuation axis (order no. 106761)
Use long actuation axis and protective sleeve and short-
en to required length
50 mm 63 mm 71 mm Standard escape release
with 110 mm axis
(order no. 100465)
and
extended actuation axis (order no. 106761)
Use long actuation axis and protective sleeve and short-
en to required length
55,5
M4
250
182
D -1
D + 10,25
±1,25
D
(11,5) 55,5
Example without mounting plates:
Escape release
Handle module
Actuation axis Protective sleeve
(+4 mm per mounting plate)
(+4 mm per mounting plate)
