Operating Instructions Safety Systems
MGB-L1…-AR.-… / MGB-L2…-AR.-… and MGB-L1…-AP.-… / MGB-L2…-AP.-…
18
(translation of the original operating instructions) 2119167-07-09/23
9. Mounting
WARNING
Mounting must be performed only by authorized personnel.
With two-leaf hinged doors, one of the two door leaves must also be latched mechanically.
Use a rod latch (Item) or a double-door lock (Bosch Rexroth) for this purpose, for example.
Important!
Ì In case of ush installation, the operating distances change as a function of the installation depth
and the guard material.
Surface mounting
Flush installation
Actuating range
Actuating range
Locking
module
Locking
module
Handle module
Handle module
Tip!
Ì You will nd an animation on the mounting process at www.euchner.com.
Ì The color and labeling of pushbuttons and indicators can be modied.
For mounting steps, see Fig. 8 and Fig. 9 to Fig. 14.
Attach system such that operation of the auxiliary release as well as inspection and service are possible.
The locking screw must be screwed back in and sealed (with sealing lacquer, for example) after mounting and after every
use of the auxiliary release. Tightening torque 0.5 Nm.
