14. Technical data
NOTICE
If a data sheet is included with the product, the information on the data sheet applies in case of dis-
crepancies with the operating instructions.
Parameter Value Unit
Housing material Fiber glass reinforced plastic
Die-cast zinc, nickel-plated
Stainless steel
Dimensions See chapter 7.4. Dimension drawing on page 13
Weight
Locking module
Handle module
Escape release
0.75
1.00
0.50
kg
Ambient temperature at U
B
= DC24V -20 … +55 °C
Degree of protection
Cover not populated/populated with buttons/indi-
cators/selector switches
Cover populated with key-operated rotary switch
Cover populated with key-operated rotary switch
FS22
IP65
IP54
IP42
Safety class III
Degree of contamination 3
Installation orientation Any
Locking force F
zh
acc. to ENISO14119 2,000 N
Connection 4 cable entries M20x1.5 or plug connector
Conductor cross-section (rigid/exible)
- With cable end sleeve acc. to DIN46228/1
- With cable end sleeve with collar acc. to
DIN46228/1
0.13 … 1.5 (AWG 24 … AWG 16)
0.25 … 1.5
0.25 … 0.75
mm²
Operating voltage UB
(reverse polarity protected, regulated, residual
ripple <5%)
24 +10% / -15% (PELV) V DC
Auxiliary voltage UA
(reverse polarity protected, regulated, residual
ripple <5%)
24 +10% / -15% (PELV) V DC
Current consumption I
UB
(no load on any outputs) 80 mA
Current consumption I
UA
- With energized guard locking solenoid and
unloaded outputs OI, OL, OT and OD
- Pushbutton S (unloaded, per LED)
375
5
mA
External fuse See chapter 12.3. Fuse protection for power supply on page 24
Safety outputs FO1A/FO1B Semiconductor outputs, p-switching, short circuit-proof
Test pulses AR <1,000/AP <300 µs
Test pulse interval Min. 100 ms
Output voltage U
FO1A
/ U
FO1B
1)
HIGH U
FO1A
/ U
FO1B
U
B
-2V … U
B
LOW U
FO1A
/ U
FO1B
0 … 1 V DC
Switching current per safety output 1 … 200 mA
Switching current per control input IMP1, IMP2
and IMM
20 … 25 mA
Utilization category acc. to ENIEC60947-5-2 DC-13 24 V 200 mA
Caution: Outputs must be protected by a free-wheeling diode in the case of inductive loads.
Monitoring outputs
- Output voltage
1)
- Max. load
p-switching, short circuit-proof
U
A
- 2V … U
A
Max. 50 mA
Rated insulation voltage U
i
30 V
Rated impulse withstand voltage U
imp
1.5 kV
Resilience to vibration Acc. to ENIEC60947-5-3
Switching frequency 0.25 Hz
EMC protection requirements Acc. to ENIEC60947-5-3
