37
2119167-07-09/23 (translation of the original operating instructions)
Operating Instructions Safety Systems
MGB-L1…-AR.-… / MGB-L2…-AR.-… and MGB-L1…-AP.-… / MGB-L2…-AP.-…
EN
Characteristics acc. to ENISO13849-1
2)
Guard lock monitoring Control of guard locking
Category 4 4
Performance Level PL e PL e
PFH
D
3.7 x 10
-9
/ h
3)
2.8 x 10
-9
/ h
3)
Mission time 20 20 years
Mechanical life 1x10
6
- In case of use as door stop, and 1Joule impact
energy
0.1x10
6
B
10D
(emergency stop) 0.065x10
6
Emergency stop
Operating voltage 5 … 24 V
Operating current 1 … 100 mA
Breaking capacity, max. 250 mW
Power supply LED 24 V DC
Controls and indicators
Operating voltage UA V
Operating current 1 … 10 mA
Breaking capacity, max. 250 mW
Power supply LED 24 V DC
1) Values at a switching current of 50mA without taking into account the cable lengths.
2) Refer to the declaration of conformity for the issue date.
3) Applying the limit value from ENISO13849-1:2008, section 4.5.2 (MTTFd = max. 100 years), the employers’ liability insurance association certies a PFHd of max. 2.47 x 10
-8
.
