System 5 Digital Audio Mixing System Operation Manual CM401 Master Section
74
5.3 Solo
System 5 has an extensive solo control system that is accessed from the center section.
Press the Solo Ctrl switch in the master Solo section to display the Solo Control Panel.
Figure 5-9 Master Solo section (top-left) and Solo Control Panel
5.3.1 Solo Mode
The three Solo modes can be selected by pressing their respective switches in the Solo
Control Panel. Selecting one mode deselects the previous mode.
APL (After-Pan Listen): Signal is post-fader and pan (stereo)
PFL (Pre-Fader Listen): Signal is pre-fader in mono
SIP (Solo-In-Place): Allows Solo channels through to the mix busses. Mutes all channels
not soloed but not channels designated Solo-Safe (page 76). This mode allows monitor-
ing soloed channels with panning and effects if the effects returns have been designated
Solo-Safe. We do not recommend this destructive solo mode for live broadcast or for
recording a mix or dub.
Film Mode: Switches any mix busses in playback to bus temporarily so an SIP solo can
be heard.
Main
Panel
Info
Solo
New Clr Name
Momentary
Summing
I/C
APL
PFL
SIP
Mod
Clear
Film Mode
Backstop PFL
Solo-Safe
DimCR
Solo>None
Solo>Alt1
Solo>Alt2
Solo>Flw
L4
L3
L2
L1
T1
LR phase
T2
CR
Output
Comms
Ctrl
Solo
Ctrl
Solo
