PROTEUS user manual
Issue C
14
Features
COM Express Standalone
Ethernet
Gigabit Ethernet port supporting 10/100/1000 BaseT.
9 9
Output to board-to-board connector.
9 8
Output to board edge RJ-45 connector.
8 9
Serial ATA
Supports two SATA output to board-to-board connector.
9 8
Output to one SATA connector.
One power connector for SATA drive.
8 9
Serial ports
One port used to connect to on-board GPS receiver or
ZIF connector
Optional
Optional
One port used to connect to on-board Bluetooth module
OR nanoZigBee OR ZIF connector (build options).
Optional
Optional
One port used to connect touch screen controller.
9 9
One port used for general purpose RS232 TX/RX port.
9 9
PCI Express
Two x1 PCIe MiniCard sockets (from PCIE switch).
Four x1 PCIe to COM Express board-to-board
connector.(One from chipset, three from PCIE switch)
9 8
x1 PCIe MiniCard socket (from PCIE switch).
x1 PCIe MiniCard socket (from Poulsbo).
8 9
SDIO/MMC
One MicroSD socket.
9 9
One 8 bit SD on ZIF connector.
8 9
GPIO
Eight GPIO on COM express connector.
9 8
Eight GPIO on header.
9 9
TPM
Atmel Trusted Platform Module Device, TCG v1.2
compatible
SMBUS interface.
9 9
COM Express
board-to-board
connector
Four PCI Express, LPC, four USB host, SMBus/I2C, HD
Audio, one LVDS video outputs, Gigabit Ethernet, two
SATA, system and control, Power.
9 8
GPS Receiver
20-channel GPS receiver SirFStar III chipset module. Optional
Optional
Bluetooth OR
ZigBee (build
option)
Bluetooth wireless communication provided by on-board
WT11 Bluetooth module. Optional
Optional
ZigBee interface provided by an on-board NanoZigBee
module.
Optional
Optional
