Comparison of PROTEUS variants
Issue C
13
Comparison of PROTEUS variants
Features
COM Express Standalone
Processor
Intel
®
Atom™ processor options:
Z530 processor 1.6GHz TDP: 2.3W.
Z510 processor 1.1GHz TDP: 2.0W.
9 9
Chipset
Intel US15W chipset: US15W TDP: 2.3W.
9 9
Supported OS
Windows XP, XP Embedded,CE, Embedded Linux.
9 9
Memory
DDR2 SDRAM: up to 1GB (400/533MHz).
9 9
BIOS
Insyde H20 BIOS - EFI and legacy support.
SPI Flash (proprietary interface).
9 9
Flash
Up to 4GB parallel ATA Thunderbolt Flash on board. 2GB 2GB
Graphics
Ultra low power integrated 3D graphics.
9 9
One single-channel LVDS 24-bit interface to COM
Express. One single-channel LVDS 24-bit interface to
connector
* (Note: for PROTEUS V1I1 see below)
9 8
Two single-channel LVDS 24-bit interface to two
connectors.
One backlight connector.
* (Note: for PROTEUS V1I1 see below)
8 9
PROTEUS V1I1
Two single-channel LVDS 24-bit interfaces to COM
Express.
9 8
PROTEUS V1I1
One single-channel LVDS 24-bit interface.
One backlight connector.
8 9
Audio
HD Audio interface on board-to-board connector.
9 8
HD Audio CODEC and 2W audio amplifier supporting
two speakers, line in, mic in and headphone.
8 9
Touch Screen
4, 5 and 8 wire resistive touch screen support.
9 9
USB Support
USB 2.0 supporting low/full/high speed modes.
Two ports connected to PCI Express MiniCard socket.
Two user accessible ports (Pin header, one client
configurable).
9 9
Four ports on board-to-board connector.
9 8
One port to board edge Type A connector.
One port to ZIF connector.
8 9
