Connectors and LEDs
The PROTEUS has the following connectors:
Connector Function Connector details in section
J1 USB 1, connector Type A J1 - USB Type A connector
, page 43
J2 SATA J2 - SATA connector, page 43
J3 GBe Ethernet J3 - GB Ethernet connector
, page 44
J4 LVDS A J4 - LVDS A connector
, page 45
J5 Power J5 - Power connector
, page 46
J6 System J6 - System connector
, page 47
J7 USB 0/2 J7 - USB0/2 header
, page 50
J8 RS232 J8 - RS232 header
, page 50
J9 GPIO J9 - GPIO header
, page 51
J10 FAN 1 J10 - FAN 1 connector
, page 51
J12 SIM J12 - SIM card socket
, page 52
J13 PCIe Minicard slot 0 J13 - PCI Express Mini Card slot 0
,
page 53
J14 PCIe Minicard slot 1 J14 - PCI Express Mini Card slot 1
,
page 53
J17 Audio J17 - Audio connector
, page 55
J18 Touchscreen J18 - Touchscreen connector
, page 55
J19 Misc ZIF connector J19 - Misc ZIF connector
, page 56
J20 Backlight J20 - Backlight
, page 57
J21 LVDS B J21 - LVDS B connector
, page 58
J22 COM express connector J22 - COM Express connector
, page 59
J23 SATA power connector J23 - SATA power connector
, page 62
J24 Micro SD slot J24 - Micro SD slot
, page 63
J25 GPS antenna connector J25 - GPS antenna
, page 63
J26 FAN 2 J26 - FAN 2 connector
, page 64
J27 EC serial debug output J27 - EC serial debug output
, page 64
The diagrams on the following page show the location of the connectors on the
PROTEUS.
