Features of standalone variants
Issue C
7
Features of standalone variants
Processor
• Intel
®
Atom™ processor options:
Z530 Processor 1.6GHz TDP: 2.3W, or
Z510 Processor 1.1GHz TDP: 2.0W.
Chipset
• Intel US15W chipset TDP: 2.3W.
System memory
• DDR2 SDRAM (up to 1GB 400/533MHz).
Supported OS
• Windows XP, XP Embedded, CE.
• Embedded Linux.
BIOS
• Insyde H20 BIOS - EFI and legacy support.
• SPI Flash (proprietary interface).
On board flash
• Up to 4GB parallel ATA Thunderbolt Flash on board (2GB default).
Graphics
• Ultra low power integrated 3D Graphics.
• Two single-channel LVDS 24-bit interfaced to two connectors.
• One backlight connector.
PROTEUS V1I1 only supports one single-channel LVDS interface on the LVDS A
connector.
Audio
• HD Audio CODEC and 2W audio amplifier supporting stereo speakers, line in,
microphone and headphone.
Touch screen
• 4, 5 and 8 wire resistive touch screen support.
