USB support
• USB 2.0 supporting low/full/high speed modes.
• Two ports connected to PCI Express MiniCard sockets.
• Two user accessible ports (Pin header, one client configurable).
• One port to board edge Type A connector.
• One port to ZIF connector.
Ethernet
• Gigabit Ethernet port supporting 10/100/1000 BaseT.
• Output to board edge RJ-45 connector.
Serial ATA
• One SATA connector.
• One power connector for SATA drive.
Serial ports
• One port used to connect to on-board GPS receiver OR ZIF connector (build option).
• One port used to connect to on-board Bluetooth module OR nanoZigBee OR ZIF
connector (build option).
• One port used to connect touch screen controller.
• One port used for general purpose RS232 TX/RX port.
PCI Express
• Two PCIe MiniCard sockets (one with SIM card slot).
SDIO/MMC
• One MicroSD socket.
• One 8 bit SD on ZIF connector.
GPIO
• Eight GPIO on header.
TPM
• Atmel Trusted Platform Module Device, TCG v1.2 compatible.
• SMBUS interface.
GPS receiver (build option)
• 20-channel GPS receiver SirFStar III chipset module.
Bluetooth OR ZigBee (build option)
• Bluetooth wireless communication provided by on-board Bluetooth module.
• ZigBee interface provided by an on-board NanoZigBee module.
