27
5. Remove energy management system.
a. If you want to connect the Audi Wallbox
to another energy management system,
you must rst unpair the previously
paired one. After that you will see a
list of available energy management
systems in the network from which you
can select another.
b. If you want to remove the paired energy
management system, click on “Cancel
pairing”.
c. If it was successfully removed, you will
be informed with a notication, and you
again can search for EEBus devices in
the network.
Check the Power Settings of the Audi
Wallbox
1. Navigate through the Conguration
Manager’s menu Power Settings.
2. Verify or set the correct DIP-switch
settings.
a. If you want to see the DIP-switch
conguration without opening the Audi
Wallbox housing, you can see here the
DIP-switch conguration.
b. If you have set the DIP-switches for the
conguration of the overload protection
to manual conguration (”To be set by
user”), you can insert here the correct
parameters for your used CT-coils (rated
primary current and the turn ratio).
3. Get information about further settings
a. You get the information if the ground
monitoring is enabled or disabled (de-
fault set to “enabled”).
b. You get the information if the overload
protection mechanism is enabled or
disabled.
c. You get the information about the con-
gured maximum charging current per
phase (default set to 16A).
Select the Preferred Language
1. Navigate through the Conguration
Manager’s menu Language Settings.
2. Select the favored language for the Con-
guration Manager.
Change the Login Password for the
Conguration Manager
1. Navigate through the Conguration
Manager’s menu User Preferences.
2. In the menu Login Password, you can
enter your current password you want to
have changed. Then enter your new pass-
word twice and conrm with clicking on
the “Change Password” button.
Software Updates and Information
1. Navigate through the Conguration
Manager’s menu Maintenance.
2. In the menu Device Information, you
see the part-/ and serial number of the
main-boards, the MAC addresses, and
the software version of the installed
software.
3. In the menu Software Update, you see
the software version of the currently
installed software. Normally you get
software updates automatically. If you
have a software le that you want to
install manually, you can click on “Brow-
se”, select your software le and click on
“Upload And Install”. The installation
will start, and the Audi Wallbox will re-
boot automatically.
4. In the menu Factory Reset, you can reset
all settings of the Audi Wallbox to the
default settings that are set initially
after manufacturing.
The software update will only be in-
stalled when no car is plugged. As soon as
you unplug your car, the software update
process will start.
All personal data and custom settings
will be lost requiring the conguration of
the Audi Wallbox to be redone.
