61
Commissioning
General Commissioning
Before connecting the wallbox to the vehicle:
1. Clean the connection zone.
2. Check wall mounting for stability.
3. Check that all screws and terminal con-
nections are tight.
4. Make sure there are no knock-out holes
for cable routing left open. Seal them
with blind plugs if there is no cable routed
through them.
5. Make sure all cable glands are tightly
closed.
6. Perform visual inspection according to
commissioning protocol. If you need a
commissioning protocol, you can down-
load it from www.elli.eco/download.
7. Switch on the input power to the wall-
box.
8. Check HMI LED status indication.
9. Perform electric commissioning accor-
ding to commissioning protocol and
normative requirements and additio-
nal local installation requirements (if
applicable).
10. Perform functional tests with a simula-
tor or an EV and simultaneously check
HMI LED status indication.
11. To comply with safety and legal regula-
tions you must ll in the commissioning
protocol.
Danger
Not following the instructions given in this document will result in the risk of electric shock
to users, which will cause severe injuries or death.
› The installation must only be performed by certied electricians, who can correctly and
safely install the wallbox and identify potential danger.
