3.2. Technical speci@cations
Feature Description
Electrical properties
Maximum charge rate Up to 22 kW (3 phase - 32 A).
Charging mode Mode 3 EVSE (IEC 61851-1).
Fixed charging cable Type 2 plug (IEC 62196-2).
Charging cable length 6 m.
Connection capacity
1-phase, 230 V, 16 A or 32 A, 50 Hz.
3-phase, 400 V, 16 A or 32 A, 50 Hz.
Metering * 3-phase S-Bus MID-certified kWh meter.
Environment and safety class
Upstream installation protection See Power supply requirements on page 13.
Operating temperature range -25° C to +45 °C.
Storage temperature range -25 °C to +60 °C.
Maximum installation altitude 2000 m.
Enclosure ratings IP55 (IEC 60529), IK10 (IEC 62262).
Safety class Safety Class I and overvoltage Category III.
Connectivity
Authorization RFID reader (Mifrare 13.56 MHz).
Communication standard Wi-Fi 2.4/5 GHz and Bluetooth 4.0 (Hub only).
Cellular communication * 4G / 2G (Hub only).
Hub-Satellite RF communication 869 MHz
Physical properties
Dimensions (W x H x D) 184 x 328 x 161 mm.
Dimensions cable dock (W x H x D) 122 x 197 x 94 mm.
3. Product features
EN
9
