EVCO S.p.A. EVDRIVE03 | User manual ver. 3.7 | Code 144EPDE374
Page 49 of 76
AlgS - - - - - - - - - - - - - - - - User
SH algorithm status
b0: measure not acquired
b1: algorithm halted
b2: bypass algorithm (manual)
b3: LoSH algorithm is running
b4: LoSH alarm
b5: HiSH algorithm is running
b6: HiSH alarm
b7: LOP algorithm is running
b8: LOP alarm
b9: MOP algorithm is running
b10: MOP alarm
b11: LP
b12: LP alarm
CoWA 0 21 - - - - - - - - User
configuration warnin
0 = correct configuration
1 = incorrect configuration for start-up
2 = invalid value for parameter Pia1
3 = invalid value for parameter Pia2
4 = invalid value for parameter Pia3
5 = invalid value for parameter Pia4
6 = Piu1 configuration matches other
Piux
7 = Piu2 configuration matches other
Piux
8 = Piu3 configuration matches other
Piux
9 = incorrect configuration Piu4
10 = mismatch between Pia1 and Piu1
11 = mismatch between Pia2 and Piu2
12 = mismatch between Pia3 and Piu3
13 = mismatch between Pia4 and Piu4
14 = awaiting configuration AI1
15 = awaiting configuration AI2
16 = awaiting configuration AI3
17 = awaiting configuration AI4
18 = awaiting analog configurations
19 = error writing Xmax probe 4 scaling
20 = error writing Xmax probe 4 scaling
21 = no primary temperature or
pressure probe configured
22 = copy valve parameters error
23 = valve selection error
PAtt 0.00 100.00 % - - - - User actual valve position
PAtP - - - - - - - - step - - - - User actual valve position step
