18 19
Tether Strap
2. Place the child restraint in position.
Set child restraint on vehicle seat in forward-facing
position. ALWAYS make sure bottom of child restraint
sits flat on vehicle seat and positioned, as shown. Lay
the Tether Strap over the back of the vehicle seat.
Lower Anchor Bar
Lower Anchor Bar
Near Side
Far side
3. Attach Lower Anchor Hooks.
With the Lower Anchor harness through the upper
belt path, as shown above,
attach a Lower Anchor
Hook onto the Vehicle Lower Anchor Bar on each side
of the child restraint.
IMPORTANT: Make sure both Lower Anchor Hooks are
facing upward, as shown, and the Lower Anchor Straps are
not twisted.
Installation with Lower Anchor Hooks
With 5-Point Harness
4. Secure the child
restraint.
Using your full weight,
push the child restraint
firmly into the vehicle
seat while pulling up on
the Lower Anchor Strap
to tighten.
Upper
Belt Path
IMPORTANT: To properly protect the child, the child
restraint MUST NOT move more than 25 mm (1 inch) from
side to side or from front to back at the upper belt path.
If you cannot tightly secure the child restraint, try again or
move it to another location, or install with the vehicle seat
belt.
5.
Connect and tighten
Tether Strap.
Connect the Tether Hook to the anchor behind the
vehicle seat, as shown. (Please consult your vehicle
owner’s manual, as Tether Anchor locations may
vary.) Pull the strap and tighten the Tether securely.
Note: The installed seat should be positioned as shown
above.
Installation with Lower Anchor Hooks
IMPORTANT:
• The Tether Strap MUST be used when installing this
child restraint with the Lower Anchor Hooks.
• If your Tether Strap is too short to reach your vehicle
Tether Anchor, you will need a Tether Extender. Please
call ParentLink at 1-800-233-5921
(U.S.) or 1-937-
773-3971 (Canada), or 01-800-706-12-00 (Mexico).
Correct Incorrect
Upper
Belt Path
Upper
Belt Path
