40 41
Converting into a Booster Seat
7. Reattach the seat pad.
Your child restraint is now in Booster Mode and ready
for a child who weighs
18 – 54.4 kg (40 – 120 lbs), is
112 – 145 cm (44 – 57 in.) tall, is at least four years
old, and whose ears are below the top of the child
restraint headrest.
6. Remove the crotch
strap.
Locate the crotch strap
anchor on the bottom.
Turn the anchor sideways
and push it through the
seat shell to remove, as
shown.
Insert the crotch strap
anchor back into the
opening from the bottom
of the child restraint.
Pull the anchor through
the seat and adjust so it
lies flat, as shown.
Converting into a Booster Seat
Booster With Backrest
Note: To convert the seat back into 5-point harness mode,
reverse these steps.
