61
Using the Quick Connectors
When the Quick Connector
LATCH assembly is in the
forward-facing belt path,
store each Quick Connector
by snapping it onto a D-ring,
as shown.
When the Quick Connector
LATCH assembly is in the rear-
facing belt path, store each
Quick Connector by snapping
it onto a D-ring, as shown.
To remove the Quick Connector from a LATCH anchor or
its storage D-ring, pull the red Release Strap.
Release Strap
