Pre-Installation (continued)
PACKAGE CONTENTS
C
B
D
Part Description Quantity
A Condensate Pump 1
B Pump Inlet Covers 3
C Wires with Pre-crimped connectors 1
D 20’ of 3/8” ID Clear Vinyl Tubing 1
MOC.TOPEDEMOH 5
.ecnatsissa rehtruf rof 877-528-3878-1 tcatnoc esaelP
Installation (continued)
1
NOTE: To mount to a wall, proceed to step 2.
□ Determine the condensate pump (A) location.
A
2
Mounting the pump to a wall
□ Determine the condensate pump (A) location allowing 8 in.
for distance between the mounting tabs.
□ Attach mounting screws (1) (not included). Use wall
anchors (2) (not included) for support in drywall or concrete
walls.
□ Mount the condensate pump (A) onto mounting screws (1).
□
NOTE: The pump top is reversible. It may be turned
around to allow easy access to the pump outlet or power
connection as may be required by the particular installation.
2
A
1
1
2
3
Levelling the pump
□ Use a level to ensure that the condensate pump (A) is level.
A
To Next Page
