7 For Professional Technical Support call 1-844-241-5521
Care and Cleaning
Do
Do Not
When the power is disconnected, inspect the pump suction
screen and remove all debris, then plug the pump back into
the grounded (GFCI) outlet.
Do not disassemble the motor housing. This motor has NO
repairable internal parts, and disassembly may cause
leakage or dangerous electrical wiring issues.
Do not lift up the pump by the power cord.
If the pump is not running properly
Remove the impeller cover screws (#1),
Remove the impeller cover (#2),
Inspect the O-ring (#3) and impeller (#4). If the impeller wears out, replace the impeller. The brushes could run 200 hours. If the brushes
have been worn off, replace the brush as the picture shows.
The brush must enter the square hole. Match the brush curve to the armature curve.
If there are any damages to these parts, please contact the pump experts at 1-844-241-5521.
NOTE: Do not disassemble the motor housing of the pump. This motor has NO repairable internal parts, and
disassembling may cause a dangerous electrical wiring issue.
Item Description Qty
1 Screw 6
2 Impeller cover 1
3 O ring 1
4 Impeller 1
5 Shaft 1
6 Brushes 2
7 Brush cap 2
8 Washer 1
9 Hose connection 1
