2. PROPANE CONNECTION: ATTACH THE SMALL WOK BURNER HOSE TO THE BBQ MANIFOLD (SEE ABOVE)
CONNECTING THE GAS SUPPLY TO THE WOK BURNER
1. CHECK THE GAS TYPE OF THE WOK BURNER (LABEL ON BOTTOM OF WOK BURNER SERVERY) MATCHES
THAT OF THE BBQ.
FLINDERS, NORFOLK, DAINTREE & KIMBERLEY TROLLEY ASSEMBLY
K
WOK BURNER GAS SUPPLY HOSE
CONNECTION TO BBQ MANIFOLD
IS DONE FROM INSIDE THE TROLLEY
HOLE IN TROLLEY SIDE FOR HOSE
GAS SUPPLY HOSE AND
REGULATOR
THROUGH THE HOLE IN THE LEFT HAND TROLLEY SIDE PANEL. CONNECT GAS HOSE AND REGULATOR
TO THE GAS CYLINDER (SEE PAGE 4 FOR OTHER INSTALLATION AND LEAK TEST INSTRUCTIONS).
3. NG CONNECTION: ALL GAS FITTING WORK, SERVICE AND REPAIRS CAN ONLY BE PERFORMED BY AN
AUTHORISED PERSON IN ACCORDANCE WITH AS5601 / AG601 AND LOCAL GAS REGULATIONS.
INSTRUCTIONS FOR AUTHORISED PERSON: FIT SMALL WOK BURNER HOSE TO BBQ MANIFOLD (SEE PAGE 4
FOR OTHER INSTALLATION AND LEAK TESTING INSTRUCTIONS).
24
