2. ALIGN THE HOLE IN THE CABINET TOP (PART 12) WITH THE HOLE IN THE LARGE INFILL PANEL (PART 11)
TO THE REAR INFILL PANEL (PART 11). FULLY TIGHTEN THE SCREW.
3. PLACE 1 x ST3.5x10 SCREW (PART 17) THROUGH THE HOLE OF THE CABINET TOP (PART 12) AND ATTACH IT
ATTACHING THE CABINET TOP TO THE TROLLEY
1. PLACE THE CABINET TOP (PART 12) ONTO THE BARBECUE CARCASS ENSURING THAT THE SAFETY EDGES
ARE FACING DOWN. SEE VIEW 'A' ABOVE FOR DETAILS.
FLINDERS, NORFOLK, DAINTREE & KIMBERLEY TROLLEY ASSEMBLY
L
VIEW 'A'
11
12
17
25
