Everlast EV1000 - Weight Stack and Support Assembly

26
81
48
20
21
21
20
58
27
26
3
9
Assembly Instructions
Step 4
c: Insert the Selection Rod (20) into
the middle hold of the Weight Plate
(27).
Slide the Top Weight Plate (26)
onto the Weight Guide Rod (21).
Use the Weight Stack Pin (58) to
select the desired weight.
a:
b:
c:
a: Slide the 14pcs x Weight Plate
(27) onto the Weight Rod (21).
b: Slide the Selection Rod Bushing
(48) in line with the Top Hole of the
Selection Rod (20) fix using the
Selection Rod Pin (81).
