Everlast EV1000 - Page 8

3
24
60
78
60
78
24
05
69
79
79
83
4
8
Assembly Instructions
a:
b:
Step 3
a: Attach 2pcs x Shroud Bracket
(24) onto the Rear Base Frame (3)
using 4 sets x Bolt (60) and Washer
(78).
b: Attach the Upright Support
Tube (5) onto the Seat Tube (4)
using 2pcs x Hex Bolt (69), 4pcs x
Washer (79) and 2pcs x Nylon Nut
(83).
