rU2 1 600 sec 60 60
Cycle time for the starting of the humidier (only for rU0 = 1, see also uU3)
rU3 1 600 sec 60 60
Humidier starting time within the cycle time uU2 to obtain 100% humidity inside cell
(only for rU0 = 1, see also rU2)
rU4 0 1 ¬¬¬¬ 0 0
Enabling of humidication/dehumidication control during the block phases, the preser-
vation and the manual cooling operations
rU5 1 100 %r.H. 5 5
Variations of dehumidifcation
rU6 0 100 %r.H. 5 5
Value of dehumidifcation neutral zone
rU7 0 255 sec 10 10
Duration of dehumidication attempt with pumpdown-type solenoid valve
rU8 1 100 %r.H. 5 5
Variations of humidication
rU9 0 100 %r.H. 5 5
Value of humidication neutral zone
rU1 0 0 50 %r.H. 10 10
Value of humidication proportional band
rU1 1 0 255 s 60 60
Cycle time to adjust humidication proportional band
rU1 2 0 1 ¬¬¬¬ 1 1
Time base for cycle time to adjust humidication proportional band 0 = seconds 1 =
minutes
rU1 3 0 100 ¬¬¬¬ 100 100
Maximum humidity set
Par. Min. Mas. Unit Dough
Retarder-Proofer
Compressor protection
C0 0 240 min 0 0
Compressor delayed starting in respect of unit starting
C1 0 240 min 0 0
Minimum lapse of time between two compressor starting operations
C2 0 240 min 5 5
Minimum duration of compressor switching-off
C3 0 240 s 0 0
Minimum duration of compressor switching-on
C4 0 240 min 0 0
Duration of forced compressor starting at the beginning of the proong phases, the lea-
vening and the delayed baking operations
C6 0 199 °C 60 60
Condenser temperature above which the overheated compressor alarm is activated
(code “COH”)
C7 0 199 °C 65 65
Condenser temperature above which the blocked compressor alarm is activated (code
“CSd”)
C8 0 15 min 1 1
Blocked compressor delayed alarm (code “CSd”)
Par. Min. Mas. Unit Dough
Retarder-Proofer
Defrosting
d0 0 99 h 6 6
Defrost interval 0 = defrost at intervals will never be activated
d1 0 1 ¬¬¬¬ 0 0
Type of defrost 0 = elettrical (during defrosting the compressor will be switched-off, the
defrost output will be activated and the evaporator fan will be switched-off) 1 = with hot
gas defrosting (during defrosting the compressor will be switched-on, the defrost output
will be activated and the evaporator fan will be switched-off)
d2 ¬99 99 °C 8 8
End-of-defrost temperature (evaporator temperature); see also the d3 parameter
d3 0 99 min 30 30
If the P3 parameter is set to 0, duration of defrost if the P3 parameter is set to 1, maxi-
mum defrost duration ; see also the d2 parameter, 0 = defrost will never be activated
d5 0 99 min 0 0
Delayed defrost in respect of the starting of the preservation phase/manual cooling ope-
ration 0 = defrost wll be activated after the time set with paramenter d0 is over
d7 0 15 min 2 2
Duration of dripping (during dripping the compressor and the evaporator fan are
switched-off and the defrost output will be deactivated)
d15 0 99 min 0 0
Minimum duration of the compressor starting when the defrosting operation is activated
to let it be started (if the d1 parameter is set to 1 only)
Par. Min. Mas. Unit Dough
Retarder-Proofer
Temperature alarms
A1 0 99 °C 50 50
Evaporator temperature above which the evaporator high temperature alarm will be acti-
vated (code “AH”); see also the A2 parameter
A2 0 1 ¬¬¬¬ 1 1
Enabling of evaporator high temperature alarm (code “AH”) 1 = yes
Par. Min. Mas. Unit Dough
Retarder-Proofer
Condenser and evaporator fan
F0 0 1 ¬¬¬¬ 1 1
Evaporator fan activity during the block phase 0 = parallel operation with compressor 1
= continuous operation
F1 0 1 ¬¬¬¬ 0 0
Evaporator fan activity during the preservation , cooling and precooling phases 0 = pa-
rallel operation with compressor 1 = continuous operation
F2 0 1 ¬¬¬¬ 1 1
Evaporator fan activity during the proong phase 0 = parallel operation with main utilities
1 = continuous operation
F3 0 1 ¬¬¬¬ 1 1
Evaporator fan activity during the leavening and heating phases 0 = parallel operation
with main utilities 1 = continuous operation
F4 0 1 ¬¬¬¬ 1 1
Evaporator fan activity during the delayed baking phase 0 = parallel operation with main
utilities 1 = continuous operation
F10 0 100 % 100 100
Fans speed during precooling phase
F11 0 100 % 100 100
Fans speed during dehumidication phase
F12 0 15 m 1 1
Fans stop after dripping phase
F13 0 250 s 0 0
Delayed evaporator fan switching-off from main utilities off
F14 1 600 sec 0 0
Evaporator fan cycle time, if set to 0, the cyclical switching-on of the evaporator will be
deactivated
F15 1 600 sec 0 0
Evaporator fan switching-on time within the F14 cycle time
F16 0 99 °C 40 40
Condenser temperature above which the condenser fan will be switched-on even if the
compressor is switched-off
F17 0 240 s 5 5
Delayed switching-off of the condenser fan from the compressor switching-off (active if
the condenser probe is disabled, only)
F18 0 240 s 5 5
Delayed evaporator fan switching-on from the closing of the door, i.e. from the deactiva-
tion of the micro door input
F19 0 100 % 100 100
Minimum speed of the evaporator fan that can be set
F20 0 100 % 100 100
Maximum speed of the evaporator fan that can be set
F21 0 100 % 100 100
Start-up wind speed of the evaporator fan
