Evolis Dualys - Manual Card Insertion

Cleaning
13
Cleaning of the printer interior
Use the Pre-Saturated Cards (UltraClean Cleaning Kit Part Number: A5011) .
Cleaning cycle: every 1000 cards.
The Dualys printer is fitted with a cleaning alert, which is activated every 1000
inserted cards. The cleaning alert LED’s switches on.
If you do not clean the printer while this LED is switched on, it will start flashing
after another 200 cards has been inserted.
Remove the feeder from
the printer as shown.
Remove the
cards present
in the feeder.
Take a new
pre-saturated cleaning
card and insert it
in the feeder as shown.
Replace the feeder
in the printer.
Check that the card
thickness is set to
0.76mm (30mil).
