11
www.evolutionpowertools.com
EN
R210MTS-G2 MACHINE OVERVIEW
1. TABLE TOP
2. TABLE SAW GUARD
3. RIP FENCE
4. PUSH STICK
5. TABLE/MITRE MODE PIN
6. BEVEL LOCKING LEVER
7. REAR STABILISING ARM
8. WORKPIECE SUPPORTS (X2)
9. TOOL STORAGE
10. RIP FENCE LOCKING LEVERS (X2)
11. TABLE TOP SCALES
2
4
3
1
7
8
9
5
6
10
10
11
11
