30
www.evolutionpowertools.com
R210MTS-G2 MASCHINENÜBERSICHT
1
3
8
1. SCHNEIDGRIFF
2. DREHTISCH
3. EINZIEHBARER UNTERER
SÄGEBLATTSCHUTZ
4. GEHRUNGSWINKEL-FESTSTELLGRIFF
5. GEHRUNGSWINKELSKALA
6. SCHNEIDKOPF-FREIGABEHEBEL
7. SPERRSTIFT FÜR SCHNEIDKOPF
8. SCHUBSTANGENABLAGE
9. TISCHKREISSÄGE EIN/AUSSCHALTER
10. GEHRUNGSSÄGE EIN/AUSSCHALTER
2
9
10
4
6
5
7
