MACHINE SPECIFICATIONS
MACHINE METRIC IMPERIAL
Motor (230-240V ~ 50 Hz) 1200W 5A
Motor (110V ~ 50 Hz) 1200W 11A
Speed No Load 3750 min
-1
3750 min
-1
Weight (Net) 5.8 kg 12.8 lbs
Dust Port Diameter 35mm 1-3/8 In.
Tool Dimensions (H x W x L) (0° / 0°)
(Note: Dimensions taken with saw head down.)
260 x 393 x 381mm
10-15⁄64 x
15-15⁄ 32 x 15 In.
Cable Length 2m 6-9⁄16 ft
CUTTING CAPACITIES METRIC IMPERIAL
Mild Steel Plate - Max Thickness 6mm 1/4 In.
Mild Steel Box Section - Max Wall Thickness
(50mm mild steel box section.)
3mm 1/8 In.
Wood – Max section 125 x 55mm 4-15/16 x 2-3/16 In.
Minimum size work-piece
(Note: Any workpiece smaller than the recommended minimum
workpiece requires additional support before cutting.)
L:140 x W:20 x D:3mm
L: 5-1/2 x W: 39/50 x
D: 1/8 ln
MAXIMUM CUTTING ANGLES LEFT RIGHT
Mitre 0 - 45˚ 0 - 45˚
Bevel 0˚ - 45˚ N/A
MITRE BEVEL
MAX WIDTH
OF CUT
MAX DEPTH
OF CUT
0° 0° 125mm (4-15/16 In.) 55mm (2-3/16 In.)
0° 45° 125mm (4-15/16 In.) 35mm (1-3/8 In.)
45° 0° 85mm (3-3/8 In.) 55mm (2-3/16 In.)
45° 45° 85mm (3-3/8 In.) 35mm (1-3/8 In.)
BLADE DIMENSIONS METRIC IMPERIAL
Diameter 210mm 8-1/4 In.
Bore 25.4mm 1 In.
Thickness 1.7mm 1/15 In.
NOISE DATA
Sound Pressure L
PA
(No-Load) 110V~ 92.1dB(A) / 230V~ 93.1dB(A), K=3dB(A)
Sound Power Level L
WA
(No-Load) 110V~ 105.1dB(A) / 230V~ 106.1dB(A), K=3dB(A)
Uncertainty, K
pA
& K
WA
3 dB(A)
> The maximum permissible system impedance Zmax at the interface point of the user’s supply is 0,238Ω. The user shall determine in
consultation with the supply authority, if necessary, that the equipment is connected only to a supply of that impedance or less.
