2. Configuration
2.1. Hypermotion Management
Remote Panel Assignment
In setups where several LSM Remote Panels and a hypermotion camera are defined, the
assignment of the various PGMs and hypermotion camera to the LSM Remote Panels is
automatically performed as shown in the table below depending on:
• the number of PGMs in the selected channel configuration
• the selected Remote Mode (Hypermotion only or Hypermotion + LSM)
• the number of Remote Panels available
The following table presents the possible configurations:
# of Remotes 1 2 3 4
Hypermotion
Mode
Hyperm.
Only
Hyperm.
+ LSM
Hyperm.
Only
Hyperm.
+ LSM
Hyperm.
Only
Hyperm.
+ LSM
Hyperm.
Only
Hyperm.
+ LSM
1 OUT
NA R1: PGM1
+hyperm.
R1: PGM1
R2:
hyperm.
NA NA NA NA NA
2 OUT
NA R1: PGM1
+PGM2
+hyperm.
R1: PGM1
+PGM2
R2:
hyperm.
R1: PGM1
R2: PGM2
+hyperm.
R1: PGM1
R2: PGM2
R3:
hyperm.
NA NA NA
3 OUT
NA R1: PGM1
+PGM2
+PGM3
+hyperm.
R1: PGM1
+PGM2
+PGM3
R2:
hyperm.
R1: PGM1
+PGM2
R2: PGM3
+hyperm.
R1: PGM1
+PGM2
R2: PGM3
R3:
hyperm.
R1: PGM1
R2: PGM2
R3: PGM3
+hyperm.
R1: PGM1
R2: PGM2
R3: PGM3
R4:
hyperm.
NA
4 OUT
NA R1: PGM1
+PGM2
+PGM3
+hyperm.
R1: PGM1
+PGM2
+PGM3
R2:
hyperm.
R1: PGM1
+PGM2
+PGM3
R2: PGM4
+hyperm.
OR
R1: PGM1
+PGM2
R2: PGM3
+PGM4
+hyperm.
R1: PGM1
+PGM2
R2: PGM3
+PGM4
R3:
hyperm.
R1: PGM1
+PGM2
R2: PGM3
R3: PGM4
+hyperm.
R1: PGM1
+PGM2
R2: PGM3
R3: PGM4
R4:
hyperm.
R1: PGM1
R2: PGM2
R3: PGM3
R4: PGM4
+hyperm.
‘PGM1+PGM2’ can represent the 2PGMs mode as well as the PGM/PRV mode.
Warning
The cells with ‘NA’ correspond to impossible configurations taking into account
the existing constraints. In this case, the Hypermotion option is not available in
the operational menu even if the Hypermotion setting is set to ‘Yes’.
USER MANUAL Multicam LSM 12.05 Hypermotion Cameras
