Cue Points Management
• When a new ARM/REC command is issued on a block, all its cue points are cleared.
• Cue points can only be marked when working with single-block memory.
• If the Last Cue command cannot access the desired TC preroll, the player remains on
the current cue point.
• If the Last Cue command refers to a TC that does not exist anymore, the player
jumps to the beginning of the current memory block.
3.3.5. Hi-Motion II Camera
Camera Names
The cameras manufactured by NAC/Ikegami are sold as Hi-Motion II cameras on the
market.
Application Start
At application start, this camera is in ARM mode and the recording starts on the first
memory block.
Parameter Values
The tables below list the parameter value, or value range that are specific to the camera.
The configuration parameters are defined in the Multicam Configuration window,
Operation page, Hypermotion controller section.
Configuration Parameter Value
Port RS422
Protocol Sony 9-PIN
The operational parameters are defined in the Hypermotion mode of the Remote Panel, in
the LCD secondary menu.
Operational Parameter Value Range Default Value
# Blocks 1 to 4 1
Pre-Roll from 00s00fr to 5s00fr 00s00fr
PGMSpeed 50, 100, 200, 300, 400,1000% 100
2nd Lever +/- 1000%, 0-1000% +/- 1000
26 3. Operation
EVS Broadcast Equipment SA Issue 12.05.A- May 2014
