Example
The following steps provide an example for a typical use of the LSM Remote commands
with a hypermotion camera:
1. Initially, the blocks are recorded or empty
Block 1 Block 2 Block 3 Block 4
2. Press RECORD on the remote to delete any recorded material on the blocks and start
the recording in loop mode on block 1 (first use of this key).
Block 1 Block 2 Block 3 Block 4
3. Press TAKE to stop recording on the current block, and start recording on the next
available one (block 2). At the same time, the playback starts on block 1.
Block 1 Block 2 Block 3 Block 4
4. Press CLEAR to stop the playback on block 1 and delete the material recorded on that
block. Block 2 is still recording, and becomes block 1.
Block 1 Block 2 Block 3 Block 4
5. Press TAKE to stop the record on block 1 and start the record on the first empty block
(block 2). Playback starts on block 1.
Block 1 Block 2 Block 3 Block 4
6. Press CAM D. The Remote beeps because the block is empty.
Block 1 Block 2 Block 3 Block 4
7. Press TAKE again to stop the record on block 2 and start it on the first available block
(block 3). The running playback on block 1 is not affected.
Block 1 Block 2 Block 3 Block 4
8. Press CAM A to cue up block 1 at the beginning. The record carries on on block 3.
Block 1 Block 2 Block 3 Block 4
9. Press TAKE to stop the recording on block 3 and start it on the first available block
(block 4).
Block 1 Block 2 Block 3 Block 4
10. Press TAKE to stop the record on block 4. As no free block is available, the recording
does not start on another block.
Block 1 Block 2 Block 3 Block 4
11. Press CLEAR +C to delete the material on block 3. Block 4 shifts to the left (becomes
block 3). Recording starts on block 4.
Block 1 Block 2 Block 3 Block 4
12. Once block 4 has been recorded, the record ends as all the other blocks contain
recorded material.
24 3. Operation
EVS Broadcast Equipment SA Issue 12.05.A- May 2014
