3.2.5. Managing Memory Blocks
Defining the Number of Memory Blocks
Some cameras allow the users to split the memory into several blocks of the same size.
Before recording material on the hypermotion camera, you should specify how many
memory blocks you are going to use (1, 2, 3, or 4 blocks). By default, only one memory
block is defined.
Note
When using more than one memory block, the blocks are considered as
independent units. That means that you have to manually shift from one block to
the other to continue recording on the next block.
To define the number of memory blocks on a hypermotion camera, proceed as follows:
1. In the hypermotion menu, press MENU to open the secondary menu.
2. Press A to activate the # Blocks field. This field specifies into how many memory
blocks the camera memory will be split.
3. Jog to select the number of blocks (1 to 4).
4. Press MENU again to validate your choice and come back to the hypermotion main
menu.
The camera memory is now split into the requested number of blocks, all with the same
size. The A to D CAM keys now correspond to the 1 to 4 memory blocks respectively.
Color Code for Memory Block Status
The memory blocks status are displayed using a common color code both directly on the
corresponding CAM keys on the LSM Remote Panel, and on the OSD monitoring of the
recorder corresponding to the hypermotion camera.
On the OSD monitoring, the block system is displayed as a suite of 4 squares, nnnn,
each corresponding to a memory block.
