3.2.2. LCD Menu on the Remote Panel
Hypermotion Main Menu
The hypermotion main menu displays the memory blocks that have been selected in the
#Blocks parameter of the hypermotion secondary menu. The memory blocks use is
described later in this chapter.
Only the activated blocks will be displayed and the highlighted block is the one the
operator is currently working on.
Off Ramp UP SpeedBrk LSM Mode
Block 1 Block 2
Cues Parameter
This parameter allows you to activate the cue management in hypermotion mode.
The default value of the Cues parameter is On.
Off Ramp UP SpeedBrk LSM Mode
Block 1 Block 2
Last Cue Parameter
The Last Cue parameter defines the Last Cue button function when the Cuesparameter is
Off.
Off Ramp UP SpeedBrk LSM Mode
Block 1 Block 2
• The Last cue parameter can be set to Ramp Up (the default value):
◦ The first time the Last Cue button is pressed, the speed is increased starting from
the PGMSpeed until the maximum speed is reached. This maximum speed
depends on the camera model.
◦ Whenever the Last Cue button is pressed again, the speed is increased starting
from the last speed used until the maximum speed is reached.
• The Last Cue parameter can be set to an individual speed (the available values
depends on the camera model).
Note
• When Cues is set to Off, the cam key is displayed in black and the Mark
button is inactive.
• When Cues is set to Off and Last Cue is set to Ramp Up, press
Clear+Last Cue to reset the speed to PGMSpeed.
USER MANUAL Multicam LSM 12.05 Hypermotion Cameras
3. Operation 11
