Camera Models
This section applies to the following Vision Research camera models:
• Phantom V642
• Miro Series
• Phantom Flex4K
Application Start
At application start, the recording does not start automatically.
Parameter Values
The tables below list the parameter value, or value range that are specific to the camera.
The configuration parameters are defined in the Multicam Configuration window,
Operation page, Hypermotion controller section.
On Vision Research cameras, two protocols can be used, each with a different port:
Values Port Protocol
Value set 1 RS422 ASCII
Value set 2 Ethernet TCP
The operational parameters are defined in the Hypermotion mode of the Remote Panel, in
the LCD secondary menu.
Operational Parameter Value Range Default Value
# Blocks 1 to 4 1
Pre-Roll from 00s00fr to 5s00fr 00s00fr
PGMSpeed 50, 100, 200, 300, 400,1000% 100
2nd Lever +/- 1000%, 0-1000% +/- 1000
Specific Behavior of Remote Panel Keys
• RECORD: Pressing this key while the current block is recording clears all memory
blocks and starts recording on the first one.
• RECORD: The Remote beeps if the CAM key refers to an empty block.
• TAKE: This key is operational in any mode.
• CLEAR: Press this key to delete the current memory block data.
